EPDM Steel Wire Braided Industrial Steam Hose Heat Resistant

Ask Lasest Price
Brand Name :	LETONE
Model Number :	LT1004-A/LT1004-B
Price :	10USD-200USD
Payment Terms :	T/T
Supply Ability :	Annual output of 1000,000 meters
Delivery Time :	1 month

Add to Cart

Product Details
Company Profile

EPDM Steel Wire Braided Industrial Steam Hose Heat Resistant

LT1004-A/LT1004-B 270 PSI EPDM Braided Steam Hose

Use safely

For steam application, it is recommended to use rubber hoses with fittings assembled with safety clamps. Over time, material (rubber) exposed to steam gradually loses its natural elasticity causing leakage or even rupture of the fitting, often with catastrophic effects. Fittings attached by safety clamps can be re-tightened over the hose service life. For safety reasons, we caution against using rubber hoses with fittings permanently crimped with ferrules.

Applications: The transfer of saturated steam up to 270 PSI AND 430℉(+220℃). Use with superheated steam will shorten hose life. Proper draining of steam hose after each use will increase service life

Tube: Black extruded EPDM-heat-resistant

Reinforcement: High tensile steel wire braids

Cover: Red or black EPDM rubber, heat resistant, surface texture, using pinhole technology

Working Pressure: Constant Pressure-18 Bar (270 PSI)

Temperature Range: -40℃(-40°F)to +220℃(+430°F)

Parameter

Series	I.D. (in.)	I.D. (mm)	O.D. (in.)	O.D. (mm)	Max.W.P.(psi)	Min.B.R.	W. (kg/m)
LT1004A/B-050	1/2	13	0.91	23	270	5	0.42
LT1004A/B-075	3/4	19	1.22	31	270	71/2	0.77
LT1004A/B-100	1	25	1.50	38	270	10	0.89
