LTSA599 Super Artery Hose , Spiral Wire Hose Low Bending Radius

Ask Lasest Price
Brand Name :	LETONE
Model Number :	LTSA599
Certification :	Hose execution SAE100R12 standard, GB/T10544-2013 standard
Price :	1USD-20USD
Payment Terms :	T/T
Supply Ability :	Annual output of 5000,000 meters
Delivery Time :	Within a month

Add to Cart

Product Details
Company Profile

LTSA599 Super Artery Hose , Spiral Wire Hose Low Bending Radius

LTSA599 Super Artery Steel Wire Spiral Hydraulic Hose

Application: Suitable for using oil base hydraulic oil, is suitable for the harsh conditions of high temperature and medium pressure hose

Tube: CR/NBR synthetic rubber

Reinforcement: Multispiral high tensile super flexible steel wire, four plies≥ 1 million impulse cycles

Cover: Skiving-free black narrow cloth texture hose cover made of anti-aging synthetic rubber

Temperature Range: -40℃~+121℃(-40℉~+250℉)

Standard: ISO 18752-DC

Features: Low bending radius; high pressure ; long service life ( weather resistant for more than 5 years and warrantied for 2 years with Letone specific hose connectors)

Parameter

TYPE	SIZE	I.D.	W.P.	B.P.	Min.B.R.
TYPE	(in.)	(mm)	(MPa)	(MPa)	(mm)
SA599-4DC	3/8'	9.5	56	224	100
SA599-4DC	1/2'	12.7	42	168	140
SA599-4DC	5/8'	15.9	42	168	180
SA599-4DC	3/4'	19	42	168	200
SA599-4DC	1'	25.4	42	168	250
SA599-4DC	11/4'	31.8	35	140	400
SA599-4DC	11/2'	38.1	29	116	480
SA599-4DC	2'	50.8	25	100	650
SA599-6DC	11/4'	31.8	42	168	400
SA599-6DC	11/2'	38.1	42	168	480
SA599-6DC	2"	50.8	42	168	650
